StarTech.com POEEXT1G60W network extender Network repeater Black 100, 1000 Mbit/s

£172.37 incl. VAT

16 in stock

Free delivery by Tuesday 29 September

MPN: POEEXT1G60W

Warranty: 2 Years

Rugged PoE Extender | 60 Watts | IP-30 Aluminum Housing | 100m (330ft)
Extend the Reach of PoE Links up to 328 Feet
Extends the reach of PoE links up to 328′ (100 m) to power powered devices (PD) over long distances; up to 4 extenders can be cascaded to extend the range of a PoE source (PSE) device up to an additional 400m, for a total range of 500m from the original PSE source to the target device.
Using Cat 5e (or higher rated) Ethernet cabling, it supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), and IEEE 802.3bt (PoE++ / Type 3) to support PD devices like pan and tilt cameras, lighting, sensors, and wi-fi access points.
Designed for Harsh Environments
This PoE extender features IP-30 housing and an MTBF is 500,000+ hrs (Telcordia/Bellcore) at 50C, for long-term reliability and durability. Operating temp of -40C to 75C permits use in a wide range of indoor and outdoor applications that are not temperature controlled.
Rated to various vibration, shock, and free-fall standards:
Vibration: EN 60068-2-6
Shock: EN 60068-2-27
Free-Fall: EN 60068-2-32
PoE Extender also includes hardware for mounting to the DIN rail or wall.
Flexible Power Outputs
Accepts inputs up to 95W from a PSE source and can provide 15W, 30W, or 60W of power output to a target PD device. Low 2.7W power consumption provides more power for devices, especially when multiple extenders are used for a single extension.
Features ESD, EFT, and surge protection at the following standards:
ESD: IEC 61000-4-2: Contact: 6KV; Air: 8KV
EFT: IEC 61000-4-4: Power: 2KV; Signal: 2KV
Surge: IEC 61000-4-5: Power: 2KV; Signal: 2KV
POEEXT1G60W is backed by a StarTech.com two-year warranty and free lifetime technical support.
The StarTech.com Advantage
– 100M EXTENSION: Extend a PSE source (up to 95W) by 100m using this Gigabit PoE Extender; power PoE devices like cameras & access points; 4 extenders can be cascaded to extend up to 400m using CAT 5e/6
– 60W PoE IEEE 802.3bt: Powered by the PSE source, this Power over Ethernet range extender provides up to 15W/30W/60W of auto-negotiated power output to target PD device
– Low 2.7W power consumption

Essential Info:

Rugged PoE Extender | 60 Watts | IP-30 Aluminum Housing | 100m (330ft)

Extend the Reach of PoE Links up to 328 Feet

Extends the reach of PoE links up to 328' (100 m) to power powered devices (PD) over long distances; up to 4 extenders can be cascaded to extend the range of a PoE source (PSE) device up to an additional 400m, for a total range of 500m from the original PSE source to the target device.

Using Cat 5e (or higher rated) Ethernet cabling, it supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), and IEEE 802.3bt (PoE++ / Type 3) to support PD devices like pan and tilt cameras, lighting, sensors, and wi-fi access points.

Designed for Harsh Environments

This PoE extender features IP-30 housing and an MTBF is 500,000+ hrs (Telcordia/Bellcore) at 50C, for long-term reliability and durability. Operating temp of -40C to 75C permits use in a wide range of indoor and outdoor applications that are not temperature controlled.

Rated to various vibration, shock, and free-fall standards:

Vibration: EN 60068-2-6

Shock: EN 60068-2-27

Free-Fall: EN 60068-2-32

PoE Extender also includes hardware for mounting to the DIN rail or wall.

Flexible Power Outputs

Accepts inputs up to 95W from a PSE source and can provide 15W, 30W, or 60W of power output to a target PD device. Low 2.7W power consumption provides more power for devices, especially when multiple extenders are used for a single extension.

Features ESD, EFT, and surge protection at the following standards:

ESD: IEC 61000-4-2: Contact: 6KV; Air: 8KV

EFT: IEC 61000-4-4: Power: 2KV; Signal: 2KV

Surge: IEC 61000-4-5: Power: 2KV; Signal: 2KV

POEEXT1G60W is backed by a StarTech.com two-year warranty and free lifetime technical support.

The StarTech.com Advantage

- 100M EXTENSION: Extend a PSE source (up to 95W) by 100m using this Gigabit PoE Extender; power PoE devices like cameras & access points; 4 extenders can be cascaded to extend up to 400m using CAT 5e/6
- 60W PoE IEEE 802.3bt: Powered by the PSE source, this Power over Ethernet range extender provides up to 15W/30W/60W of auto-negotiated power output to target PD device
- Low 2.7W power consumption

Specs

Performance
Type	Network repeater
Maximum transfer distance	100 m
Data transfer rate	1000 Mbit/s
Cable types supported	Cat5e, Cat6
Chipset	Realtek RTL8367, Microsemi PD69101
Ethernet LAN data rates	100,1000 Mbit/s
Auto-negotiation	✓
Flow control support	✓
Mean time between failures (MTBF)	551848 h
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ports & interfaces
Power over Ethernet (PoE) ports quantity	2
Design
Product colour	Black
Housing material	Aluminium
LED indicators	✓
Certification	CE, FCC
Power
Power consumption (typical)	2.7 W
Power over Ethernet (PoE)	✓
Total Power over Ethernet (PoE) budget	60 W

Operational conditions
Operating temperature (T-T)	-40 - 75 °C
Weight & dimensions
Width	81.5 mm
Depth	104 mm
Height	32 mm
Weight	148 g
Management features
Supported network protocols (IPv4)	CSMA/CD
Technical details
Sustainability certificates	RoHS
Packaging content
Quick start guide	✓
Packaging data
Package width	211 mm
Package depth	162 mm
Package height	64 mm
Package weight	390 g
Logistics data
Harmonized System (HS) code	85176990
Master (outer) case width	355 mm
Master (outer) case length	345 mm
Master (outer) case height	225 mm
Products per master (outer) case	10 pc(s)

Additional information

EAN	0065030889650
Product type	Network Extenders
Brand	StarTech.com
