Allied Telesis AT-SP10SR network transceiver module Fiber optic 10300 Mbit/s SFP+ 850 nm
Original price was: £215.98.£215.98Current price is: £215.98. incl. VAT
8 in stock
Free delivery by Tuesday 29 September
MPN: AT-SP10SR
Warranty: 2Years
767035194660
The Allied Telesis AT-SP10SR is a hot pluggable 10Gbps small form factor transceiver module. It is compliant with the SFF-8431 SFP+ Electrical Multi-source Agreement (MSA) with five digital monitoring functions: Temperature, Vcc, Tx optical power, Tx laser bias current and Rx received optical power.
The Allied Telesis AT-SP10SR is a hot pluggable 10Gbps small form factor transceiver module. It is compliant with the SFF-8431 SFP+ Electrical Multi-source Agreement (MSA) with five digital monitoring functions: Temperature, Vcc, Tx optical power, Tx laser bias current and Rx received optical power.
Specs
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 10300 Mbit/s |
| Interface type | SFP+ |
| Multi-mode fiber (MMF) supported | ✓ |
| Fiber optic connector | LC |
| Maximum transfer distance | 300 m |
| Wavelength | 850 nm |
| Tx power (min) | -5 dBmW |
| Tx power (max) | -1.8 dBmW |
| Rx power (min) | -30 dBmW |
| Rx power (max) | -11.1 dBmW |
| Power | |
|---|---|
| Power consumption (typical) | 1 W | Operational conditions |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 85% | Technical details |
| Sustainability certificates | RoHS | Logistics data |
| Harmonized System (HS) code | 85369010 |
Additional information
| EAN | 767035194660 |
|---|---|
| Product type | Network Transceiver Modules |
| Brand | Allied Telesis |
