ATEN VS184B-AT-G video splitter 4x HDMI
£147.24 incl. VAT
Out of Stock
MPN: VS184B
4719264645419
The VS184B True 4K HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMIenabled equipment, such as DVD players, satellite set- top boxes and all HDMI monitors, displays, projectors, or TVs.
The VS182B True 4K HDMI Splitter is HDMI 2.0 compliant, 4K at 60Hz (4:4:4), and supports multiple streaming audio, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings.
The VS184B True 4K HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMIenabled equipment, such as DVD players, satellite set- top boxes and all HDMI monitors, displays, projectors, or TVs.
| Ports & interfaces | Value |
|---|---|
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.0 |
| Video ports quantity | 5 |
| DC-in jack | ✓ | Features | Value |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | ✓ |
| Maximum operating distance | 5 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 600 MHz |
| HDCP version | 2.2 |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| HDCP | ✓ |
| Plug and Play | ✓ |
| LED indicators | ✓ | Power | Value |
| AC input voltage | 5 V |
| Power consumption (typical) | 4.84 W | Weight & dimensions | Value |
| Width | 80 mm |
| Depth | 200 mm |
| Height | 25 mm |
| Weight | 680 g |
| Packaging data | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 830 g | Packaging content | Value |
| Manual | ✓ |
| Cables included | HDMI |
| AC adapter included | ✓ | Operational conditions | Value |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% | Logistics data | Value |
| Master (outer) case net weight | 13.6 kg |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 315 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case height | 338 mm |
| Master (outer) case gross weight | 17.7 kg |
| Products per master (outer) case | 20 pc(s) |
