D-Link DES-1016D Unmanaged Fast Ethernet (10/100) Black

£53.92 incl. VAT

Out of Stock

MPN: DES-1016D/B

The DES-1016D 16-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.

Ideal for Basic Networking Tasks
With the D-Link DES-1016D, you can easily expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

Auto-Sensing 10/100 Ports
The DES-1016D use auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to 10 or 100 Mbps devices to create an integrated network. Each port automatically adjusts for straight-through or crossover cables to make the right link.

Flow Control for Secure Transmission
802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full.

Quality of Service (QoS)
The switches provide 802.1p priority queues for QoS, allowing users to run bandwidth-sensitive applications such as multimedia and VoIP Internet telephone without data flow bottlenecks that can degrade the quality of the network connection.

Save on Energy Costs
The switches support IEEE802.3az EEE which enables the switches to reduce power consumption when the switches are at low utilization, allowing users to save on power usage and costs. During these periods of low utilization, the switches can enter a low-power state and use up less power than regular operations.

The DES-1016D 16-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.

Ideal for Basic Networking Tasks
With the D-Link DES-1016D, you can easily expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

Auto-Sensing 10/100 Ports
The DES-1016D use auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to 10 or 100 Mbps devices to create an integrated network. Each port automatically adjusts for straight-through or crossover cables to make the right link.

Flow Control for Secure Transmission
802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full.

Quality of Service (QoS)
The switches provide 802.1p priority queues for QoS, allowing users to run bandwidth-sensitive applications such as multimedia and VoIP Internet telephone without data flow bottlenecks that can degrade the quality of the network connection.

Save on Energy Costs
The switches support IEEE802.3az EEE which enables the switches to reduce power consumption when the switches are at low utilization, allowing users to save on power usage and costs. During these periods of low utilization, the switches can enter a low-power state and use up less power than regular operations.
Management featuresValue
Switch typeUnmanaged
Quality of Service (QoS) support✓
Ports & interfacesValue
Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
NetworkValue
Networking standardsIEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support✘
Copper ethernet cabling technology100BASE-TX, 10BASE-T
Full duplex✓
Flow control support✓
Auto MDI/MDI-X✓
Auto-sensing✓
Data transmissionValue
Switching capacity3.2 Gbit/s
MAC address table8000 entries
Store-and-forward✓
Maximum data transfer rate0.2 Gbit/s
ProtocolsValue
Supported network protocolsCSMA/CD
DesignValue
Rack mounting✘
Stackable✘
Product colourBlack
LED indicatorsActivity, Link, Power, Power
PerformanceValue
Internal memory2 MB
Mean time between failures (MTBF)2266559 h
PowerValue
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)2.89 W
Power over Ethernet (PoE)Value
Power over Ethernet (PoE)✘
Operational conditionsValue
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Heat dissipation9.86 BTU/h
Weight & dimensionsValue
Width280 mm
Depth125.8 mm
Height44 mm
Packaging dataValue
Package width282 mm
Package depth376 mm
Package height78 mm
Package weight1.8 kg
Technical detailsValue
Shipping (inner) case height31.1 cm
Shipping (inner) case width39.2 cm
Shipping (inner) case length42 cm
Shipping (inner) case net weight9 kg
Products per shipping (inner) case5 pc(s)
Pallet gross weight (air)253.9 kg
Master (outer) cases per pallet (air)24 pc(s)
Products per pallet (air)120 pc(s)
Pallet gross length120 cm
Pallet gross width110 cm
Pallet height (air)137.9 cm
Pallet gross weight (sea)372.3 kg
Master (outer) cases per pallet (sea)36 pc(s)
Products per pallet (sea)180 pc(s)
Pallet height (sea)2 m
Shipping (inner) case gross weight9.87 kg
CertificatesValue
CertificationFCC Class A, ICES-003 Class A, CE Class A, C-Tick Class A, VCCI Class A, LVD, cUL
Logistics dataValue
Harmonized System (HS) code85176990
